Rhino Ecolam 1630
Mid-level single-side laminator for signage and graphic applications that keeps lamination bubble-free with consistent quality. Supplied by CMYK Digital Solutions from Sharjah with installation guidance and after-sales support across the UAE, GCC and Africa.
Description
- Laminate up to 1600 mm width; substrates up to 20 mm thickness can be mounted
- High quality 120 mm diameter silicon rollers for wear resistance and efficiency
- Use with cold lamination films for single-side lamination at speeds up to 9 m/min
Features
- Pivoting feeding tray for easy loading of media and laminating film
- Release liner re-winder and media take-up reel
- Foot pedal control for hands-free operation
- Automatic roller height adjustment (pneumatic pressure system)
- Infrared temperature control
- Anti-fold device
Specifications
| Working width | 160 cm / 63″ |
|---|---|
| Substrate thickness | Up to 20 mm |
| Roller material | Silicon |
| Speed | Up to 9 m/min |
| Height adjust | Pneumatic pressure |
| Pressure adjust | Pneumatic pressure |
| Roller diameter | 120 mm / 5″ |
| Heated method | Infrared |
| Preheat time | 5–10 mins |
| Power | 0.5–0.8 kW/h (1000 W) |
| Power requirement | 110/220 V, 50–60 Hz |
| Gross weight | 150 kg |
| Dimensions | 70 × 2080 × 1250 mm |
| Air compressor | Provided |
| Flatbed | Optional |
| Brand | Rhino |
| Supply | CMYK Digital Solutions — UAE, GCC & Africa |
